Power Mobility Products

True mid-wheel drive: 20.6″ turning radius

Robust independent suspension can absorb up to 250 lbs on the footplate without tipping forward

Premium, semi-reclining ergonomic seat; up to 135°

Dynamic LiNX controller for convenient Bluetooth programming and diagnostics

16″ seat width with 16″ – 18″ depth adjustability, 18″ – 20″ seat widths with 18″ – 20″ depth adjustability

Includes red or blue shrouds

Weight Capacity 300 lbs

Drivetrain MWD

Seat Type Captain or Pan

Seat Width 16”-20"

Seat Depth 16"- 20"

Backrest Height 20"

Seat-to-Floor Height A: 20.5”-22.5” D: 21.5"-29.5"

Elevating Seat P326D - 7.5"

Overall Length 34"

Overall Width 24"

Overall Height 48.5"

Turning Radius 20"

Ground Clearance 2"

Total Weight 184 lbs, 214 lbs

Wt of Heaviest Pc 90 lbs, 120 lbs

Max Speed 5 mph

Per Charge Range up to 18 miles

Motor DC 24V, 160W

Controller Dynamic LiNX 40A

Battery Size (2) 12V/U1 (34AH)

Charger 4A off-board

Gradient 6 °

Front Wheels 6" solid

Drive Wheels 10" solid

Rear Wheels 6" solid

Group Group: 2

HCPCS Code K0822/K0823 P326D: K0823

Standard Colors Red or Blue

Weight capacity 300 lbs

Detachable, height and width adjustable armrests

Removable, replaceable seat and back covers

18" seat width, ergonomic seating design

Semi-reclining back rest 90°-135°

Simplified frame construction

Compact, lightweight design

Easy access to components

9" Drive wheels, 6" castors

Excellent maneuverability

Flip up footplate

Max Speed up to 4 mph

Range up to 18 miles

Turning Radius 21"

Ground Clearance 2.4"

Motor DC 24V, 130W

Controller Dynamic LiNX

Battery 12V/U1(34AH) x 2pcs

Charger 4A off-board

Gradient 6°

Casters 6" foam filled tires

Drive Wheels 9" foam filled tires

Brakes Intelligent,

True mid-wheel drive: 20.7” turning radius

Robust independent suspension can absorb up to 350 lbs on the footplate without tipping forward

Premium, semi-reclining ergonomic seat, up to 135°

12” knobby drive tires for superior traction

Dynamic LiNX & Shark controller for convenient Bluetooth programming and diagnostics

20” seat width with 18”-20” depth adjustability

22” or 24” seat widths with 20”-22” depth adjustability

Weight Capacity 450 lbs, 400 lbs w/lift

Drivetrain MWD

Seat Type Captain or Pan

Seat Width P327: 22", P3274: 20”

Seat Depth P327: 22”, P3274: 20”

Backrest Height 22"

Seat-to-Floor Height P327: 22”-23” P3274: 24”-34”

Elevating Seat P3274 - 10"

Overall Length 35.4"

Overall Width 27.2"

Overall Height 48"

Turning Radius 21"

Ground Clearance 2.2"

Total Weight 243 lbs, 273 lbs

Wt of Heaviest Pc 121 lbs, 151 lbs

Max Speed 5 mph

Per Charge Range up to 20 miles

Motor DC 24V, 300W x 2pcs

Controller Dynamic Shark 50A

Battery Size (2) 12V/22NF (50AH)

Charger 5A off-board

Gradient 8 °

Front Wheels 6" solid

Drive Wheels 12" flat-free

Rear Wheels 6" solid

Group Group 2: Heavy Duty

HCPCS Code K0824/K0825 K0830/K0831

Dynamic LiNX controller for easy programming and diagnostics

18” x 16” ergonomic, semi-reclining, high-back seat: up to 135°

9” knobby drive tires for superior traction

Compact, light weight and easily disassembles into three pieces

Weight Capacity 300 lbs

Drivetrain RWD

Seat Type Captain

Seat Width 18"

Seat Depth 16"

Backrest Height 17"

Seat-to-Floor Height 18" - 20"

Elevating Seat n/a

Overall Length 33"

Overall Width 23"

Overall Height 35"

Turning Radius 23"

Ground Clearance 2"

Total Weight 135 lbs

Wt of Heaviest Pc 66 lbs

Max Speed 4.5 mph

Per Charge Range up to 12.5 miles

Motor DC 24V, 120W

Controller Linx 40

Battery Size (2) 12V/18-22AH

Charger 3A off-board

Gradient 8°

Front Wheels 7" solid

Drive Wheels 9" foam filled

Rear Wheels 3" anti-tippers

300 lbs. weight capacity

Up to 4 mph

24.75" turning radius

Up to 13.5 miles per charge

In-line, front-wheel drive technology provides tight turns around corners

Comfortable, depth-adjustable, limited recline high-back seat with headrest

40-apm, PG GC 3 controller

Optimal indoor maneuverability in small spaces

Large front wheels for extra absorption over obstacles

Available in Candy Apple Red

HCPCS Code: Group 2: Standard (K0822/K0823)

Weight Capacity 300 lbs.

Turning Radius1 24.75"

Width1 22.75"

Length1,2 34.75"/41" (with footplate)

Maximum Speed3 Up to 4.0 mph

Ground Clearance1 1.85" at motors

Front Wheels 3" solid anti-tips

Drive Wheels 9" solid

Rear Wheels 6" solid casters

Drivetrain Two motor, in-line, front-wheel drive

Braking System Regenerative and electro-mechanical

Suspension Type Limited

High-Back Seat (max. size) 20"W x 20"D

High-Back Seat-to-Floor Range 21.5” – 23.5”

Standard Electronics 40A, PG GC3

Battery Size (2 required) 12 volt, U-1

Standard Battery Charger 3.5A, off-board

Per-Charge Range3,6 Up to 15 miles

Battery Weight5 25 lbs. each

HCPCS Group 2: Standard (K0822/K0823)

Weight of Heaviest Piece4 69 lbs.

Standard Seat Weight 50.2 lbs. (comfort, high-back)

Standard Seat Size 16" x 16"-18"

18" x 18"-20"

20" x 18"-20"

450 lbs. weight capacity

Up to 4 mph maximum speed

24" turning radius

Up to 14.4 miles per charge

Comfortable, depth-adjustable, limited recline high-back seat with headrest

Easy rear access to batteries

Intuitive controller is easy to operate

Color-through shroud

Angle-adjustable foot platform offers greater comfort

Front-wheel drive design for excellent maneuverability

14" knobby tires and optimum weight distribution provide superior traction

40A Dynamic LiNX controller

Weight Capacity 450 lbs.

Turning Radius1 24"

Width1 24.25"

Length1,2 35.5"

Maximum Speed3 Up to 4.0 mph

Ground Clearance1 3"

Front Wheels 3" solid anti-tips

Drive Wheels 14" foam filled

Rear Wheels 6" solid casters

Drivetrain Two motor, front-wheel drive

Braking System Regenerative and electro-mechanical)

Suspension Type Limited

High-Back Seat (max. size) 24"W x 24"D

High-Back Seat-to-Floor Range 20” – 22”

Synergy® Seating 24”W – 24”D

Synergy® Seat-to-Floor Range 15.75” – 17.75”

Standard Electronics 50 A Dynamic

Battery Size (2 required) 12 volt, NF-22

Standard Battery Charger 5A, off-board

Per-Charge Range3,7 Up to 14.4 miles

Battery Weight6 37 lbs. each

Weight of Heaviest Piece4 99 lbs.

Standard Seat Weight 18" wide - 51.8 lbs.

20" wide - 54 lbs.

22" wide - 57.6 lbs.

Standard Seat Size 20" x 18"-20"
